GUI with drag being choppy

Help and Feedback Scripting Support
,
1

I seriously don’t know how to title this post but basically I was making this gui that has like drag(?)

I’ll just show with a video.

https://gyazo.com/cbca042e56deee1303ddde5bc245e072.mp4

The GUI has the drag effect but it’s kinda choppy, and I’m too desperate to find a solution or a better way to do it. Here’s my current code:

local cam = workspace.Camera
local frame = game.Players.LocalPlayer:WaitForChild("PlayerGui"):WaitForChild("ScreenGui").Frame
local prev = CFrame.new(0, 0, 0)

game["Run Service"].RenderStepped:Connect(function(dt)
	workspace.Part.CFrame = cam.CFrame * CFrame.new(0, 0, -10)
	local view = workspace.Camera:WorldToScreenPoint(prev.Position)
	prev = workspace.Part.CFrame
	frame.Position = UDim2.fromOffset(view.X, view.Y)
end)

Any help would be greatly appreciated.

2

Why do you have prev? As far as I can see, it’s off by 1 render step because of it. prev gets set after WorldToScreenPoint gets assigned to view which is being used to position the frame.

3

prev is the Previous CFrame of the part, that what makes the drag effect possible.

4

Why don’t you take the current part CFrame and take WorldToScreenPoint with it? Is there a reason to use the previous CFrame of the part?

5

Yeah.. to make the gui have that drag effect? else it would be a static GUI.

6

Then I would use Heartbeat or BindToRenderStep to take previous CFrame. They are closer to RenderStepped than one more render step which shall be more precise.

1 Like
7

Yes, you should use either one of those, these should fire after physics calculations.

1 Like
8

I already had a feeling that this wouldn’t work but I tried it anyways incase I was wrong. Although the choppy-ness became less choppy but still didn’t fix it.

@PuppoJon

https://gyazo.com/ee11416747502a72363142392607f4d5

Update: I may be asking too much here, this is good enough for me. Thanks

1 Like
9

You could probably tween the position every frame. This works since tweens can override each other therefore it will tween faster as the desired distance is further.
