Hey im not sure if you figured out how to make it work like a normal ragdoll or not. But i wanted to also make a skinned-mesh ragdoll so i started off with what you made here, and i finally figured out how to make it(kinda). But there isnt much on how to make it so im gonna post the way i did it here.
–The Result: https://gyazo.com/5406bb34a07a2df69a61ffc8d534fd96
–Better Video: Roblox Skinned Mesh Ragdoll - YouTube
–Note: this method has a flaw that the meshparts and HumanoidRootPart don’t follow the ragdoll and i cant figure out a way to make it do so without the ragdoll breaking, But i hope someone here figures it out and shares it.
1, chop the mesh into separate limbs(Doesnt Have To Be R-15) And then using motor6d’s to connect them like a normal rig.
–The next part i did in a script–
2, In the script i used for i,v in pairs() to find all the mesh limbs that have a bone (for e.g: Mesh: “Head”, Bone: “mixamorig:Head”) and make a part with the same size, orientation and position as the Mesh and set its transparency to 1. And then set the CanCollide to false for the meshPart we just created a part for.
3, I make an attachment inside the part i just made and move its WorldCFrame to the WorldCFrame of the Bone its linked to. Then i spawn a function, which uses Heartbeat to move the Bone.WorldCFrame to the WorldCFrame of the attachment.
4, Then i use another for i,v in pairs() to find all the motor6d’s that both their “Part0” and “Part1” have a bone (like step 2), then i make a attachment and set the parent to the part we made in step1 which Corresponds to the meshPart inside “Part0”. And do the same for “Part1.”
(For e.g: If Part0 is “Head” i make the parent of the attachment to the part i made for “Head” in step1)
5, Move the first Attachemnt to motor6d.C0 and second Attachment to motor6d.C1
6, Create a BallSocketConstraint with the parent being the same parent as the first attachment in step4, And set its Attachment0 and Attachment1 to the attachments we made in step4.
7, Now just unanchor all the parts we made in step1 and it should ragdoll!
–Sorry if it was confusing but its my first time posting a post here, since i wanted to make skinned mesh ragdolls but i couldn’t find anything that actually works.
–My Script, It has some extra things so i can customize it more but all you need is listed in the steps above.
--Made By Callme_jj
local char = script.Parent
local CharBones = char:WaitForChild("HumanoidRootPart"):GetDescendants()
local RagDollPartsFolder = Instance.new("Folder",char) --Create Folder To Parent All GhostParts.
RagDollPartsFolder.Name = "RagDollPartsFolder"
local RunService = game:GetService("RunService")--HeartBeat To Move Bones To Attachments Location, And Move RootPart.
local RATE_PER_SECOND = 500 --How Many Times Per Second To Move Bones.
local BoneDict = { --Dictionary To Refrence Bones From Body MeshPart Name.
Head = "mixamorig:Head",
LeftFoot = "mixamorig:LeftFoot",
LeftHand = "mixamorig:LeftHand",
LeftLowerArm = "mixamorig:LeftForeArm",
UpperTorso = "mixamorig:Spine",
LeftLowerLeg = "mixamorig:LeftLeg",
LeftUpperArm = "mixamorig:LeftArm",
LeftUpperLeg = "mixamorig:LeftUpLeg",
LowerTorso = "mixamorig:Hips",
RightFoot = "mixamorig:RightFoot",
RightHand = "mixamorig:RightHand",
RightLowerArm = "mixamorig:RightForeArm",
RightLowerLeg = "mixamorig:RightLeg",
RightUpperArm = "mixamorig:RightArm",
RightUpperLeg = "mixamorig:RightUpLeg",
}
local BoneLimits = { --Dictionary To Refrence Bones Ball Socket Limits.
Head = {UpperAngle = 45, TwistLowerAngle = -22.5, TwistUpperAngle = 22.5}, --Main Parts
UpperTorso = {UpperAngle = 45, TwistLowerAngle = -35, TwistUpperAngle = 120},
LowerTorso = {UpperAngle = 45, TwistLowerAngle = -20, TwistUpperAngle = 20},
LeftUpperLeg = {UpperAngle = 35, TwistLowerAngle = 0, TwistUpperAngle = 180}, --Left Leg
LeftLowerLeg = {UpperAngle = 0, TwistLowerAngle = 0, TwistUpperAngle = 0},
LeftFoot = {UpperAngle = 1, TwistLowerAngle = -35, TwistUpperAngle = 35},
LeftUpperArm = {UpperAngle = 45, TwistLowerAngle = 0, TwistUpperAngle = 0}, --Left Arm
LeftLowerArm = {UpperAngle = 45, TwistLowerAngle = -20, TwistUpperAngle = 20},
LeftHand = {UpperAngle = 35, TwistLowerAngle = -180, TwistUpperAngle = 180},
RightUpperLeg = {UpperAngle = 35, TwistLowerAngle = 0, TwistUpperAngle = 180}, --Right Leg
RightLowerLeg = {UpperAngle = 0, TwistLowerAngle = 0, TwistUpperAngle = 0},
RightFoot = {UpperAngle = 25, TwistLowerAngle = -35, TwistUpperAngle = 35},
RightUpperArm = {UpperAngle = 45, TwistLowerAngle = 0, TwistUpperAngle = 0}, --Right Arm
RightLowerArm = {UpperAngle = 45, TwistLowerAngle = -20, TwistUpperAngle = 20},
RightHand = {UpperAngle = 1, TwistLowerAngle = -35, TwistUpperAngle = 35},
}
--Make Attachments For Each MeshPart And Position It Where The Bone Is.
for index,Child in pairs(char:GetChildren()) do
if Child:IsA("MeshPart") and BoneDict[Child.Name] then --Check If Child Is A Mesh And If A Bone Exists In Bone Dictionary.
local ChildLinkedBone
for i, Bone in pairs(CharBones) do --Get The Bone Object From The Character.
if Bone.Name == BoneDict[Child.Name] then
ChildLinkedBone = Bone
end
end
local GhostPart = Instance.new("Part", RagDollPartsFolder) --Create, Size/Position && Name GhostPart.
GhostPart.Size = Child.Size
GhostPart.CFrame = Child.CFrame
GhostPart.Name = (Child.Name.."-Ghost")
GhostPart.Anchored = true
GhostPart.Transparency = 1
GhostPart.CanCollide = true
local BoneAtt = Instance.new("Attachment", GhostPart) --Create And Position Bone Attachment.
BoneAtt.WorldCFrame = ChildLinkedBone.WorldCFrame
BoneAtt.Name = (GhostPart.Name.."-BoneAtt")
Child.CanCollide = false --Turn Off Main Mesh CanCollide.
spawn(function() --Heartbeat to move the bone's CFrame to the attachments CFrame.
RunService.Heartbeat:Connect(function(step)
ChildLinkedBone.WorldCFrame = BoneAtt.WorldCFrame
end)
end)
end
end
--Make BallSocket From Motor6d.
for index, Child in pairs(char:GetDescendants()) do
if Child:IsA("Motor6D") and BoneDict[Child.Part0.Name] and BoneDict[Child.Part1.Name] then --Check If Child Is A Motor6D And If Both Part0 and Part1 Have Ghost Bones.
local GhostPart0 = RagDollPartsFolder:WaitForChild(Child.Part0.Name.."-Ghost") --Get Ghost parts.
local GhostPart1 = RagDollPartsFolder:WaitForChild(Child.Part1.Name.."-Ghost")
local Att0 = Instance.new("Attachment",GhostPart0) --Create Attachements For BallSocket Constraint.
local Att1 = Instance.new("Attachment",GhostPart1)
Att0.Name = GhostPart0.Name.."-BallAtt" --Name Attachments For Debugging Purposes.
Att1.Name = GhostPart1.Name.."-BallAtt"
Att0.CFrame = Child.C0 --Set The Attachments CFrame To The Joints CFrame.
Att1.CFrame = Child.C1
local BallConstraint = Instance.new("BallSocketConstraint", GhostPart0) --Create BallSocket Constraint And Set Its Attachments.
BallConstraint.Attachment0, BallConstraint.Attachment1 = Att0, Att1
BallConstraint.TwistLimitsEnabled = true --Set BallSocket Limits.
BallConstraint.LimitsEnabled = true
BallConstraint.UpperAngle = BoneLimits[Child.Part0.Name].UpperAngle
BallConstraint.TwistLowerAngle = BoneLimits[Child.Part0.Name].TwistLowerAngle
BallConstraint.TwistUpperAngle = BoneLimits[Child.Part0.Name].TwistUpperAngle
print("BallSocket Constraint Created For "..GhostPart0.Name.." And "..GhostPart1.Name..".")
end
end
--UnAnchor All GhostParts.
for i,v in pairs(RagDollPartsFolder:GetChildren()) do
v.Anchored = false
end
char:FindFirstChild("HumanoidRootPart").CanCollide = false
